(1). Big square hole 1020mm*600mm*40mm / hole size is 25*20mm / weight is 2.11kg

(2). Small square hole 1020mm*600mm*40mm / hole size is 18*18mm / weight is 2.13kg

(3). Oblong hole 1200mm*500mm*40mm /hole size is 40mm*18mm / weight is 2.3kg

(4). Oblong hole 1000mm*500mm*40mm /hole size is 40mm*18mm / weight is 1.91kg

Two style triangle beam:

(1). Triangle beam (8cm height) / material: PVC / 1kg/meter

(2). Triangle beam (12cm height) / material: PVC / 1.55kg/meter

Two style support leg:

(1). Support leg A(for breeder) / Height freewill ,as the support PVC pipe can custom length

(2). Support leg B( for broiler) / Adjust height from 18cm to 28cm

poultry plastic flooring Advantage:

1. The material engineering polypropylene 100% raw material, plus patent recipe, to keep plastic modification, make the slats resist corrosion, anti-oxidants, anti-inhibitor, anti-ultraviolet, high-duty and flexible.

2. Made by modern molding, the slats finish in one-time.

3. Good leakage dung rate as the rational hole design, no burr on surface.

4. Easy to install and clean, connect one by one firmly, not only slats, but also support legs.

5. The plastic slat's bearing around 250kg.

6. Warranty of 15-20 years using life.

The plastic slat floor for chicken are suitable for chicken ,duck ,goose ,rabbit, goat and other animals and common used in modern poultry farm.

1.Pure starting materials (plastic) an injection molding, divided into brood floor,poultry floor.
2.Corrosion resistance, aging resistance. In the original package compound added antioxidants, anti-aging agents, anti-UV agents.
3.Easy to clean and disinfect, easy washable, even with a high concentration of acidic or alkaline disinfectants, will not corrode.
5.The plastic slat floor for chicken joists reinforced plastic extrusion molding, into a conservancy joists Conservancy machine Conservancy joists.
6.Disposable Conservancy height during installation, can be adjusted.
7.Birdhouse Conservancy machine conservancy channel, the best control in less than two meters.
8.Apply to chickens, ducks, geese, as well as fattening chickens, ducks, geese, and breeders.
9.Recyclable after cleaning and then add some crushed raw materials and chemical agents modified, by injection molding to the floor again after, but also with about 6 years.
